1. Download 51 LED Screen Specification PDFs
Browse LED screen specification PDFs by product model to compare equipment before purchase. This index contains 51 model datasheet links across rental, indoor, advertising, transparent, poster and stadium displays. Use the exact model and configuration column in each document, then request a project-specific confirmation before procurement.
Choose a category below, find the model name, and open its PDF datasheet. Use the document to build a shortlist, then confirm the final pixel pitch, cabinet configuration, electrical requirements and installation conditions with EagerLED before ordering. Values can vary by model, configuration and project.
- 51 model-specific PDF links are listed on this page.
- Six application categories make it easier to narrow the product family first.
- Direct PDF links let engineers, integrators and buyers review technical data without a form.
Jump to datasheets by product category
Request a model and configuration check
2. Choose the right LED display specification category
| Product category | Typical application | Specifications to compare first |
|---|---|---|
| Rental LED screens | Touring, stages, exhibitions and temporary events | Cabinet size and weight, locking system, refresh rate, brightness and maintenance access |
| Indoor LED screens | Retail, showrooms, meeting rooms and control rooms | Pixel pitch, cabinet dimensions, brightness, viewing distance and front-service access |
| Advertising LED screens | Fixed indoor or outdoor advertising, billboards and 3D displays | Brightness, IP rating, power consumption, cabinet construction and service direction |
| Transparent LED displays | Glass facades, windows, retail displays and rental installations | Transparency, brightness, cabinet structure, pixel pitch and installation method |
| Poster LED screens | Portable digital signage, retail promotions and events | Display dimensions, cabinet weight, mobility, control method and input options |
| Stadium and sports LED displays | Perimeter advertising and large-format sports venues | Cabinet protection, brightness, IP rating, refresh rate and maintenance access |
3. How to read an LED screen specification sheet
- Pixel pitch (mm) is the center-to-center distance between neighboring pixels. Compare it with the intended viewing distance and content detail.
- Brightness (nits or cd/m²) should match the ambient light at the installation. Outdoor and window-facing projects generally require different brightness planning from indoor rooms.
- Refresh rate (Hz) matters when the display will be filmed or used for live production. Check it together with grayscale and camera requirements.
- Cabinet size and weight (mm and kg) affect screen dimensions, rigging loads, transport and serviceability.
- Power consumption (W/m²) helps the electrical contractor estimate circuits, distribution and operating load. Use the final configured screen size for project calculations.
- Ingress protection (IP) describes enclosure protection against solid objects and water under IEC 60529. Check front and rear ratings separately when the datasheet lists both.
- Service access indicates whether modules, power supplies and receiving cards are maintained from the front, rear or both sides.
Check the configuration column, not only the series name
A series PDF may list several pixel pitches or indoor and outdoor configurations. Record the full variant, cabinet resolution, dimensions, service method and relevant power data from the same column. Ask EagerLED to resolve any discrepancy between a downloaded reference, the current product page and the quotation before approving an order.
Source and review note: The downloadable PDFs are EagerLED model specification sheets. This index was reviewed on October 16, 2026. PDF issue dates and configurations can differ; the index review does not revise the source documents. For tender documents, structural calculations or final electrical design, request a project-specific confirmation because product configurations can change.
4. Rental LED Screen Specifications
5. Indoor LED Screen Specifications
6. Advertising LED Screen Specifications
7. Transparent LED Display Specifications
8. Poster LED Screen Specifications
9. Stadium & Sports LED Display Specifications
10. LED Screen Specification FAQ
Does a datasheet provide the screen section detail for my building?
Use a product PDF to identify equipment dimensions and model data. It is not a project-specific section drawing, mounting design or structural approval. If your tender needs section details, send the proposed installation and service access so the required project documents and responsibilities can be agreed.
01. What specifications matter most when choosing an LED screen?
Start with pixel pitch, brightness, cabinet dimensions and weight, refresh rate, maximum and average power consumption, IP rating and maintenance access. The correct priorities depend on viewing distance, ambient light, camera use, installation method and whether the screen is permanent or rental.
02. What is included in an LED display specification PDF?
A model datasheet commonly includes module and cabinet dimensions, available pixel pitches, resolution, brightness, refresh rate, grayscale, viewing angle, power data, operating conditions, protection rating and service method. Open the individual EagerLED PDF because the available fields and values differ by product.
03. Which specification sheets are suitable for indoor and outdoor LED screens?
Use the Indoor LED Screen section for indoor fixed installations. For outdoor fixed advertising, review the Advertising LED Screen section; for temporary outdoor events, start with Rental LED Screen models. Always confirm the exact brightness, protection rating and structural requirements for the installation location.
04. Which PDFs should I review for a stadium or LED jumbotron screen?
Start with the Stadium and Sports LED Display section, including the EA960SP3, EA1600SP and EA1280SP1 specification sheets. If the project is a large fixed advertising display rather than a sports perimeter screen, compare the Advertising LED Screen models as well.
05. Is the PDF datasheet the final project specification?
No. A downloadable LED screen datasheet is a product reference, not a final engineering submittal. Confirm pixel pitch, cabinet quantity, electrical load, control system, mounting, environmental conditions and project-specific options before procurement.
06. How can I get help selecting a model?
Send the installation type, screen width and height, viewing distance, indoor or outdoor location, mounting method and camera requirements through the EagerLED contact page. The technical team can match those requirements to an appropriate model and specification sheet.
